1 Row H=1.5/1.7/2.5mm Straight Type
Home >> 1 Row H=1.5/1.7/2.5mm Straight Type
1 Row H=1.5/1.7/2.5mm Straight Type

Series: 1215/1217/1225
Part Number:
Category: Pin Header
Application: Board-to-Board, Signal
Product Status: Active

Pitch: 2.54mm
Number of Contacts: 01~40
Termination Interface Style: Through Hole
Number of Rows: Single
Stackable: No
Orientation: Straight
Mated Height: 1.50/1.70/2.50mm
PC Tail Length: Customer Specifiable
Square Pin Size: 0.64mm
PCB Locator: No
Mates With Part(s):


Material
Contact: Brass
Insulator: Hi-Temp. Thermoplastic UL94V-0

Plating
Standard: Gold Flash Over Nickel

Electrical
Current Rating: 3 AMP
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 20mΩ Max.
Dielectric Voltage: AC 1000 V
Operating Temperature: -40°C to +105°C
